2 Construction readiness for installing shower enclosures The purpose of this manual is to assist in the installation of a floor-level shower enclosure in a sloped space. In this installation method, the shower enclosure must stand on a flat part of the floor outside the sloped area. The dimensions of the sloped area must be smaller than or equal to the internal dimensions of the shower enclosure (red dimensions).

3 Construction readiness for installing shower enclosures Table of Contents Briliant BSDPS R 80 × 80 / 90 × 90 / 100 × 100 / 100 × 80 / 110 × 80 / 120 × 80 / 120 × 90 5 BSDPS L 80 × 80 / 90 × 90 / 100 × 100 / 100 × 80 / 110 × 80 / 120 × 80 / 120 × 90 6 BSRV4 80 / 90 / 100 7 Walk-In Walk-in Wall 60 / 70 / 80 / 90 / 100 / 110 / 120 / 130 / 140 / 150 / 160 8 +W Set W Set 80 / 90 / 100 Wall / Corner 8 Walk-in Corner 110 × 80 / 120 × 80 / 120 × 90 9 +W Set W Set 80 / 90 Wall / Corner 9 Walk-in Free 120 / 130 / 140 / 150 / 160 10 +W Set 90 / 100 Free 10 Walk-In Double Wall 11 +Walk-In Wall 60 / 70 / 80 / 90 / 100 / 110 / 120 / 130 / 140 / 150 / 160 11 +Walk-In Wall 60 / 70 / 80 / 90 / 100 / 110 / 120 / 130 / 140 / 150 / 160 11 +W Set W Set Uni Free/Wall 11 Walk-in Wall Air 90 / 100 / 110 / 120 12 SmartLine SMSRV4 80 / 90 13 SMSD2 R 90B / 100B / 110B / 120B + SMPS R 80 / 90 / 100 14 SMSD2 L 90B / 100B / 110B / 120B + SMPS L 80 / 90 / 100 15 Matrix MSDPS L 100 / 110 / 120×80 / 90 / 100 16 MSDPS R 100 / 110 / 120×80 / 90 / 100 17 MSRV4 80 / 90 / 100 18 Chrome CRV1 80 / 90 / 100 + CRV1 80 / 90 / 100 19 CRV1 80 / 90 / 100 + CPS 80 / 90 / 100 20 CRV2 80 / 90 / 100 / 110 / 120 + CRV2 80 / 90 / 100 / 110 / 120 21 CRV2 80 / 90 / 100 / 110 / 120 + CPS 80 / 90 / 100 22

4 Construction readiness for installing shower enclosures Table of Contents Pivot PDOP1 80 / 90 + PPS 80 / 90 / 100 23 PDOP2 100 / 110 / 120+ PPS 80 / 90 / 100 24 Cool! COSD1 80 / 90 25 COSD2 100 / 110 / 120 26 COSD1 80 / 90 + COPS 80 / 90 / 100 27 COSD2 100 / 110 / 120 + COPS 80 / 90 / 100 28 Nexty NDOP1 80 / 90 29 NDOP2 100 / 110 / 120 30 NDOP1 80 / 90 + NPSS 80 / 90 / 100 31 NDOP2 100 / 110 / 120 + NPSS 80 / 90 / 100 32 Blix Slim BLSDP2 100 / 110 / 120 33 BLSRV2K 80 / 90 / 100 / 120 + BLSRV2K 80 / 90 / 100 / 120 34 BLSDP2 100 / 110 / 120 + BLSPS 80 / 90 35 Blix BLDP2 100 / 110 / 120 36 BLDP4 120 / 130 / 140 / 150 / 160 / 170 / 180 / 190 / 200 37 BLRV2K 80 / 90 / 100 / 110 / 120 + BLRV2K 80 / 90 / 100 / 110 / 120 38 BLDP2 100 / 110 / 120 + BLPS 80 / 90 / 100 39 BLDP4 120 / 130 / 140 / 150 / 160 / 170 / 180 / 190 / 200 + BLPS 80 / 90 / 100 40 Supernova ASDP3 180 / 90 / 100 41 SRV2 75 / 80 / 90 / 100 + SRV2 75 / 80 / 90 / 100 42 ASRV3 75 / 80 / 90 + ASRV3 75 / 80 / 90 43 ASDP3 80 / 90 / 100 + APSS 75 / 80 / 90 44

5 Construction readiness for installing shower enclosures BSDPS R - 80x80 / 90x90 / 100x100 / 100x80 / 110x80 / 120x80 / Brilliant A1 B1 Brilliant BSDPS R 80 × 80 / 90 × 90 / 100 × 100 / 100 × 80 / 110 × 80 / 120 × 80 / 120 × 90 BSDPS A B L1 L2 C R V A1 B1 80 × 80 789 (789–795) 789 (783–795) 750 750 228 554 - 774 (±6) 774 (±6) 90 × 90 889 (883–895) 889 (883–895) 850 850 328 554 - 874 (±6) 874 (±6) 100 × 100 989 (983–995) 989 (983–995) 950 950 328 654 173 974 (±6) 974 (±6) 100 × 80 898 (983–995) 789 (789–795) 950 750 328 654 173 1074 (±6) 774 (±6) 110 × 80 1089 (1083–1095) 789 (783–795) 1050 750 428 654 173 1074 (±6) 774 (±6) 120 × 80 1189 (1183–1195) 789 (783–795) 1150 750 528 654 378 1174 (±6) 774 (±6) 120 × 90 1189 (1183–1195) 889 (883–895) 1150 750 528 654 378 1174 (±6) 874 (±6)

6 Construction readiness for installing shower enclosures Brilliant BSDPS L 80 × 80 / 90 × 90 / 100 × 100 / 100 × 80 / 110 × 80 / 120 × 80 / 120 × 90 BSDPS A B L1 L2 C R V A1 B1 80 × 80 789 (789–795) 789 (783–795) 750 750 228 554 - 774 (±6) 774 (±6) 90 × 90 889 (883–895) 889 (883–895) 850 850 328 554 - 874 (±6) 874 (±6) 100 × 100 989 (983–995) 989 (983–995) 950 950 328 654 173 974 (±6) 974 (±6) 100 × 80 898 (983–995) 789 (789–795) 950 750 328 654 173 1074 (±6) 774 (±6) 110 × 80 1089 (1083–1095) 789 (783–795) 1050 750 428 654 173 1074 (±6) 774 (±6) 120 × 80 1189 (1183–1195) 789 (783–795) 1150 750 528 654 378 1174 (±6) 774 (±6) 120 × 90 1189 (1183–1195) 889 (883–895) 1150 750 528 654 378 1174 (±6) 874 (±6) A1 B1

7 Construction readiness for installing shower enclosures Brilliant BSRV4 80 / 90 / 100 774 / 874 / 974 (±6) 774 / 874 / 974 (±6)

8 Construction readiness for installing shower enclosures Walk-In Walk-In Wall 60 / 70 / 80 / 90 / 100 / 110 / 120 / 130 / 140 / 150 / 160 W Set 80 / 90 / 100 Wall / Corner

9 Construction readiness for installing shower enclosures Walk-In Walk-In Corner 110x80 / 120x80 / 120 x 90 W Set 80 / 90 Wall / Corner

10 Construction readiness for installing shower enclosures Walk-In Walk-In Free 120 / 130 / 140 / 150 / 160 W Set 90 / 100 Free

11 Construction readiness for installing shower enclosures Walk-In Walk-In Double Wall Walk-In Wall 60 / 70 / 80 / 90 / 100 / 110 / 120 / 130 / 140 / 150 / 160 Walk-In Wall 60 / 70 / 80 / 90 / 100 / 110 / 120 / 130 / 140 / 150 / 160 W Set Uni Free/Wall W Set Uni Uni T spoj

12 Construction readiness for installing shower enclosures Walk-In Walk-In Wall Air 90 / 100 / 110 / 120

13 Construction readiness for installing shower enclosures SmartLine 775 / 875 (±7) 775 / 875 (±7) SMSRV4 80 / 90

14 Construction readiness for installing shower enclosures SmartLine 875 / 975 / 1075 / 1175 (±7) 775 / 875 / 975 (±7) SMSD2 R 90B / 100B / 110B / 120B SMPS R 80 / 90 / 100

15 Construction readiness for installing shower enclosures SmartLine 875 / 975 / 1075 / 1175 (±7) 775 / 875 / 975 (±7) SMSD2 L 90B / 100B / 110B / 120B SMPS L 80 / 90 / 100

16 Construction readiness for installing shower enclosures Matrix 735 / 835 / 935 (±10) 980 / 1080 / 1180 (±10) MSDPS L 100 / 110 / 120 x 80 / 90 / 100

17 Construction readiness for installing shower enclosures Matrix 735 / 835 / 935 (±10) 980 / 1080 / 1180 (±10) MSDPS R 100 / 110 / 120 x 80 / 90 / 100

18 Construction readiness for installing shower enclosures Matrix 735 / 835 / 935 (±10) 735 / 835 / 935 (±10) MSRV4 80 / 90 / 100

19 Construction readiness for installing shower enclosures Chrome 760 / 860 / 960 (±10) 760 / 860 / 960 (±10) CRV1 80 / 90 / 100 CRV1 80 / 90 / 100

20 Construction readiness for installing shower enclosures Chrome 759 / 859 / 959 (±10) 759 / 859 / 959 (±10) CRV1 80 / 90 / 100 CPS 80 / 90 / 100

21 Construction readiness for installing shower enclosures Chrome 760 / 860 / 960 / 1060 / 1160 (±10) 760 / 860 / 960 / 1060 / 1160 (±10) CRV2 80 / 90 / 100 / 110 / 120 CRV2 80 / 90 / 100 / 110 / 120

22 Construction readiness for installing shower enclosures Chrome 760 / 860 / 960 / 1060 / 1160 (±10) 759 / 859 / 959 (±10) CRV2 80 / 90 / 100 / 110 / 120 CPS 80 / 90 / 100

23 Construction readiness for installing shower enclosures Pivot (761 / 861) -10/+15 (744 / 844 / 944) -10/+15 PDOP1 80 / 90 PPS 80 / 90 / 100

24 Construction readiness for installing shower enclosures Pivot (961 / 1061 / 1161) -10/+15 (744 / 844 / 944) -10/+15 PDOP2 100 / 110 / 120 PPS 80 / 90 / 100

25 Construction readiness for installing shower enclosures Cool! COSD1 80 / 90

26 Construction readiness for installing shower enclosures Cool! COSD2 100 / 110 / 120

27 Construction readiness for installing shower enclosures Cool! COSD1 80 / 90 COPS 80 / 90 / 100

28 Construction readiness for installing shower enclosures Cool! COSD2 100 / 110 / 120 COPS 80 / 90 / 100

29 Construction readiness for installing shower enclosures Nexty NDOP1 80 / 90

30 Construction readiness for installing shower enclosures Nexty NDOP2 100 / 110 / 120

31 Construction readiness for installing shower enclosures Nexty NDOP1 80 / 90 NPSS 80 / 90 / 100

32 Construction readiness for installing shower enclosures Nexty NDOP2 100 / 110 / 120 NPSS 80 / 90 / 100

33 Construction readiness for installing shower enclosures Blix Slim BLSDP2 100 / 110 / 120

34 Construction readiness for installing shower enclosures Blix Slim BLSRV2K 80 / 90 / 100 / 120 BLSRV2K 80 / 90 / 100 / 120

35 Construction readiness for installing shower enclosures Blix Slim BLSDP2 100 / 110 / 120 BLSPS 80 / 90

36 Construction readiness for installing shower enclosures Blix BLDP2 100 / 110 / 120

37 Construction readiness for installing shower enclosures Blix BLDP4 120 / 130 / 140 / 150 / 160 / 170 / 180 / 190 / 200

38 Construction readiness for installing shower enclosures Blix BLRV2K 80 / 90 / 100 / 110 / 120 BLRV2K 80 / 90 / 100 / 110 / 120

39 Construction readiness for installing shower enclosures Blix BLDP2 100 / 110 / 120 BLPS 80 / 90 / 100

40 Construction readiness for installing shower enclosures Blix BLDP4 120 / 130 / 140 / 150 / 160 / 170 / 180 / 190 / 200 BLPS 80 / 90 / 100

41 Construction readiness for installing shower enclosures Supernova ASDP3 80 / 90 / 100

42 Construction readiness for installing shower enclosures Supernova SRV2 75 / 80 / 90 / 100 SRV2 75 / 80 / 90 / 100

43 Construction readiness for installing shower enclosures Supernova ASRV3 75 / 80 / 90 ASRV3 75 / 80 / 90

44 Construction readiness for installing shower enclosures Supernova Rozměr A1 B1 A B 75 860 710 - 710-755 80 760 760 770-805 760-805 90 860 860 870-905 860-905 100 960 760 970-1005 - ASDP3 80 / 90 / 100 APSS 75 / 80 / 90

RAVAK a. s. Obecnická 285 261 01 Příbram 1 Czech Republic tel.: +420 318 427 288 e-mail: export@ravak.com www.ravak.com The manufacturer reserves the right to make technical changes to individual products, change the appearance and packaging of the product, adjust prices, and is not liable for any printing errors
